AT3 98 A
Petrol tractor
A 98cm manual transmission lawn-tractor with a 352cc Alpina OHV engine and a side-discharge cutter-deck. Can also be set-up to mulch cuttings with the purchase of the optional kit.
- 98 cm cutting deck and strong-built side discharge funnel to manage lawns up to 4800 m2
- Equipped with powerful Alpina single-cylinder engine
- Up to 7 possible cutting height settings, to fit your lawn's needs
- Blades can be easily engaged thanks to PTO electromagnetic clutch
- Improved driving experience with ergonomic steering wheel
Product details and specs
Gardeners looking for a fast and efficient way to manage large areas of overgrown grass should take a look at the well-equipped Alpina AT3 98 A!
Its ability to handle out-of-control growth is thanks to its side-discharge cutter-deck - long grass-cuttings that would be impractical to collect are instead ejected in neat and tidy rows to the right-hand side of the tractor, thus avoiding chute-blockages and saving time by eliminating the need for emptying-stops.
The AT3 98 A has been fitted with an Alpina ST350 engine; a highly efficient four-stroke power-pack that’s capable of producing a muscular 6.5kW from a compact 352cc cylinder-capacity; and which benefits from Alpina’s noise-minimizing and emission-cutting OHV (overhead-valve) technology.
It’s equipped with large-diameter drive-wheels that provide essential traction when you’re working on inclines or damp ground; and it benefits from electromagnetic PTO engagement, so you’ll find it quick and easy to start and stop the blades.
Adaptable and flexible in use, the AT3 98 A offers seven preset heights-of-cut and combines an optional mulch-capability with a multi-speed manual drive.
Other important features include anti-scalp deck-wheels for turf-protection when maneuvering on hills and uneven ground; and an Alpina Smart seat with lower-back support for long hours of fatigue-free mowing.
Its ability to handle out-of-control growth is thanks to its side-discharge cutter-deck - long grass-cuttings that would be impractical to collect are instead ejected in neat and tidy rows to the right-hand side of the tractor, thus avoiding chute-blockages and saving time by eliminating the need for emptying-stops.
The AT3 98 A has been fitted with an Alpina ST350 engine; a highly efficient four-stroke power-pack that’s capable of producing a muscular 6.5kW from a compact 352cc cylinder-capacity; and which benefits from Alpina’s noise-minimizing and emission-cutting OHV (overhead-valve) technology.
It’s equipped with large-diameter drive-wheels that provide essential traction when you’re working on inclines or damp ground; and it benefits from electromagnetic PTO engagement, so you’ll find it quick and easy to start and stop the blades.
Adaptable and flexible in use, the AT3 98 A offers seven preset heights-of-cut and combines an optional mulch-capability with a multi-speed manual drive.
Other important features include anti-scalp deck-wheels for turf-protection when maneuvering on hills and uneven ground; and an Alpina Smart seat with lower-back support for long hours of fatigue-free mowing.
Features
Efficiency and performance in the same machine
High-performance Alpina OHV engine - enjoy smooth operation with reduced fuel-costs and less noise.
Face any challenge
Ideal for long grass, the side-discharge deck lays-out clippings in tidy rows to the tractor’s right-hand side.
Push and go!
Simply push a button and get mowing!
Choose your preferred height
You can easily choose among 7 pre-set cutting heights, from 25 to 80 mm, depending on your lawn's needs...and yours!
Technical specs
General info
EAN/UPC
8008984851177
SKU
2T0510404/A22
Power
Battery capacity
18 Ah
Power
6.5 kW
Power source
Petrol
Engine Brand
STIGA
Engine model
ST 350 Powered by STIGA
Displacement
352 cm³
Engine rotation speed
2800 rpm
Battery Voltage
12 V
Choke
Manual
Engine cooling
Air
Fuel tank capacity
6 l
Suggested working area
4500 ㎡
Cutting system
Minimum uncut radius
70 cm
Cutting width
98 cm
Reverse mowing
Yes
Blade rotation
Untimed
Cutting height adjustment
Manual with lever
Cutting height positions
7 positions
Cutting height range
25 - 80 mm
Number of blades
2
Additional cutting method
Mulching
Blade engagement type
Electric
Drive system
Traction
Rear-wheel drive
Transmission
Number of gears
5 forward + 1 reverse
Transmission method
Lever-operated
Transmission type
Mechanical
Equipment
Steering wheel
Alpina ergonomic
Seat type
Alpina smart with low back support
Seat adjustment
Screws
Dashboard
No
Front wheel size
13x5.00-6
Rear wheel size
18x8.50-8
Hour meter
No
Headlights
Conventional
Cruise control
No
Bumper
Yes
Washing link
Yes
Storage compartment
Yes
Cup holder
Yes
Pivoting front axle
Yes
Antiscalp wheels
2
Safety system
Seat with Safety Contact Breaker
Tools kit
Mulching kit
Optional
Battery charger
Optional
Trailer hitch kit
Optional
Vibration and noise data
Guaranteed sound power level (LwA) - dB(A)
100
Max vibration on driver's seat (m/s2)
0.94
Max vibration on steering wheels (m/s2)
3.33
Measured sound power level dB(A)
99
Measured sound pressure level at operator ear dB(A)
86
Overall dimensions
Pack weight
207.5 kg
Product length
1726 mm
Product width
1200 mm
Product height
1100 mm
Product weight
169 kg
Related Accessories
Support
What is the proper way to clean the lawn tractor after mowing the grass?
The exterior of the tractor mower must be cleaned with water and detergent, paying attention not to get water in the electrical system, motor and circuit board located under the instrument panel. The collection bag should be emptied and cleaned of residue, then remounted so the cutting assembly can be washed, and then removed, rinsed and allowed to dry. When washing the cutting device assembly and the expulsion chute, the collection bag or rear discharge shield must be fitted, the operator must be seated, the cutting device assembly must be in position “1”, the engine running, transmission placed in neutral and the cutting device must be connected. Then connect a water hose to the appropriate pipe fittings and allow the water to flow for a few minutes while keeping the cutting devices in motion.
What action should be carried out before winter storage or before storing it for a period longer than 30 days?
After allowing the engine to cool down and fully recharging the battery, disconnect the battery cables and store it in a cool and dry place. Empty the fuel tank, clean the machine thoroughly, check the condition of the cutting device assembly, and, if necessary, contact the service centre. Then store the lawn tractor with the cutting deck in a lowered position, in a sheltered environment and, if possible, covered with a sheet.
What action should be carried out before initially using a riding tractor that has been stored over a winter or for a period longer than 30 days?
Refuel it and check the oil level, air filter and petrol filter. Check that the tyres are correctly pressurised and then set up the lawn mower tractor according to how you intend to carry out the mowing (side discharge, collection, rear discharge, mulching). For further information about the preliminary operations and safety checks, please refer to the designated sections of the instructions manual.
What standard maintenance operations does the lawn mower tractor need?
Before each use, we recommend that you perform safety and control checks, check the tyre pressure, and replenish the fuel and oil tank, if necessary. After each use, arrange for a general cleaning of the riding tractor. Please refer to the designated section of the instruction manual (“maintenance table”) for the regular actions recommended to ensure optimal use of the machine.
What are the cutting functions of the lawn tractor?
The riding tractor can be set up in different cutting modes: rear bag collection or rear discharge, or mowing and chopping the grass using the special “mulching kit” function. The mulching cutting system allows you to mow the grass into fine particles, which remain on the lawn, restore nutrients and support growth.
What kinds of parts and accessories can the lawn tractor be equipped with?
The lawn tractor can be equipped with various parts and accessories to increase its functions and ensure maximum versatility all year round. For the complete list of parts and accessories, please refer to the relevant product page on the website.
Reach Information
Information on Article 33 of REACH Regulation concerning STIGA Group products. Discover moreReach Information
AT3 98 A
| 382722475/0 | PC BOARD SD (ISO) Waterwei | Lead | 7439-92-1 | ||||||
| 118120007/0 | BATTERY 12V 18AH [HAIJIU] | Lead | 7439-92-1 | ||||||
| 382004618/0 | DECK ENGAGE CABLE | Lead | 7439-92-1 | ||||||
| 125601567/0 | MOTOR PULLEY | Lead | 7439-92-1 | ||||||
| Component 1 | Component description 1 | Substance/s | CAS number | Component 2 | Component description 2 | Component 3 | Component description 3 | Component 4 | Component description 4 |
|---|
