AL5 46 SA

Petrol lawn mower

The 139cc AL5 46 SA is a 46cm, steel-decked petrol lawn mower with a 60-litre collector and a self-propelled drive. Powered by STIGA.
  • Collects clippings in a spacious 60-litre grassbag
  • Powered by a top-quality STIGA OHV engine
  • Mid-sized 46cm cut
  • Self-propelled – cover slopes and rough ground with ease
  • Strong and durable steel deck
Tax Included

Product details and specs

A 46cm machine with self-propulsion via the rear wheels, the Alpina AL5 46 SA will prove a fantastic purchase if you’re managing a medium- to large-sized lawn with slopes and sections of tussocky grass that would be impractical to mow with a hand-propelled model.
The AL5 46 SA is supplied with a capacious 60-litre grassbag that will keep you going for long periods between each stop for emptying. The bag has a ‘collector full’ warning indicator to let you know when capacity has been reached; and a smart-grip handle for straightforward removal and refitting.
Thanks to its steel-decked design, the AL5 46 SA will give season after season of unfailing service and won’t be troubled by any accidental impact.
A height-adjustable handlebar – with ergonomically-shaped grip – ensures a comfortable drive for any operator; while ball-bearing mounts help to keep the wheels rolling freely over time.
Convenience-features on the AL5 46 SA include simple single-point cutting-height adjustment; and a practical carry-handle.
Also important is the front grass-comb – this lifts the grass just before cutting, thereby making the finish beautifully neat and even.
Power is supplied by a 139cc/3hp four-stroke OHV AutoChoke engine from STIGA.

Features

Powerful STIGA engine
Powerful, reliable and efficient STIGA petrol engine.
Perfect for medium-large lawns
With its 46cm cut and 60-litre collection capacity.
Smart-grip handle
For hassle-free collector removal.
‘Grassbag full’ indicator
Lets you know when it’s time for an emptying-stop

What's in the box

AL5 46 SA
AL5 46 SA
Petrol lawn mower
  • lensGrass bag
  • lensPin for rear discharge

Technical specs

General info
EAN/UPC
8008984841451
SKU
2L0482044/A21
Power
Power source
Petrol
Power
2.2 kW
Engine Brand
STIGA
Engine model
ST 140 OHV Autochoke Powered by STIGA
Displacement
139 cm³
Engine rotation speed
2900 rpm
RPM control
Fixed rpm
Starter
Recoil
Fuel tank capacity
0.75 l
Engine Oil tank capacity
0.5 l
Suggested working area
1200 ㎡
Cutting system
Cutting width
46 cm
Deck material
Steel
Cutting height adjustment
Centralized
Cutting height positions
6 positions
Cutting height range
22 - 65 mm
Drive system
Driving
Self-propelled
Traction
Rear-wheel drive
Speed forward
3.7 Km/h
Equipment
Collector capacity
60 l
Handlebar type
Ergonomic
Wheels
200/200mm grooved wheels on ball bearings with soft tread
Front handle
Yes
Adjustable handlebar
Yes
Foldable handlebar
Yes
Collector type
Hybrid with warn
Vibration and noise data
Vibration level hand (m/s2)
5.9
Guaranteed sound power level (LwA) - dB(A)
96
Measured sound power level dB(A)
96
Measured sound pressure level at operator ear dB(A)
83
Overall dimensions
Pack weight
29.7 kg
Product length
1570 mm
Product width
540 mm
Product height
1100 mm
Product weight
27 kg

Support

How does the petrol mower start and where are the controls located?
This lawnmower starts to recoil. The yellow lever on the handlebar allows you to activate the blade.
How is the cutting height adjusted on this petrol lawn mower?
For this petrol lawnmower, the cutting height adjustment is carried out centrally thanks to a lever located near the wheels.
