ABR 52 D

A high-performing brushcutter, to face overgrown grass, thanks to its 51.7cc petrol engine and bike handle, for better control. Maintenance is extremely easy. Double harness ensures maximum comfort.

Perfect to cut wildly grown grass and thick vegetation, thanks to included blade
Powerful 51,7 cc petrol engine
Ergonomic bike handle, to better face demanding sessions
Easy start system to start engine even with low outside temperatures
Easy maintenance, thanks to Tap&Go nylon head
Excellent comfort, thanks to included luxury double harness

Skip to the beginning of the images gallery

With one of the largest engines to be found on any homeowner-use brushcutter - 52.7cc - the top-of-the-range Alpina ABR 52 D offers performance-levels that will be familiar to professional gardeners and is therefore capable of taking-on heavy-duty landscaping jobs!
The air-cooled two-stroke engine is rated at an impressively substantial 1.6kW (2.1hp) and benefits from Alpina’s hassle-eliminating Easy Start ignition system.
The ABR 52 D is flexible in use, with its three-tooth metal brush-blade perfect for tackling nettles, bramble and dense, overgrown grass; and its twin-line strimmer-head ideal for lighter-duty work along lawn-edges and around tree bases.
A pro-style ‘bike’-type double handlebar allows for a natural lateral ‘sweeping’ action and makes it easy to control and maneuver; while a luxury full shoulder-harness ensures it will remain comfortable to operate for the duration of the task in hand.
Thanks to a Tap & Go mechanism, renewing the cutting-cord on the line-head is quick and easy.

More Information
Shop Online	No
Short Description	A high-performing brushcutter, to face overgrown grass, thanks to its 51.7cc petrol engine and bike handle, for better control. Maintenance is extremely easy. Double harness ensures maximum comfort.
EAN/UPC	8008984833449
Unique selling point 06	Excellent comfort, thanks to included luxury double harness
Unique selling point 05	Easy maintenance, thanks to Tap&Go nylon head
Unique selling point 04	Easy start system to start engine even with low outside temperatures
Unique selling point 02	Powerful 51,7 cc petrol engine
Unique selling point 03	Ergonomic bike handle, to better face demanding sessions
Unique selling point 01	Perfect to cut wildly grown grass and thick vegetation, thanks to included blade
Key features 1 title	Get rid of overgrown grass
Key features 1 description	This brushcutter is the perfect tool to face any kind opf overgrown grass and thick vegetation.
Key features 1 image	/f/1/f12d8a85dfd8b4ef4584e1c71cb84fe895b25af9_ABR52D_287421004A20_detail01.jpg
Key features 2 title	The combination of control and comfort
Key features 2 description	The bike-style handle gives you total control on the cutting zone and more comfort for long working sessions.
Key features 2 image	/c/4/c4536cad8d211e7bfb26671780b4ad2eb1a5c917_ABR52D_287421004A20_detail02.jpg
Key features 3 title	Get cutting!
Key features 3 description	Easy Start makes getting going fast and stress-free.
Key features 3 image	/2/7/27c7bb7d9c4633dc68bc03879861a488212409d6_ABR52D_287421004A20_detail03.jpg
Key features 4 title	Easily advance the line
Key features 4 description	Advance the line by simply tapping the cutter-head on the ground!
Key features 4 image	/2/6/262b3f57eb761d57c9dc47735051ab93b8560a61_ABR52D_287421004A20_detail04.jpg
Key features 5 title	Less stress on arms and back
Key features 5 description	The double harness enhances working comfort and avoids any kind of stress on arms and shoulders.
Key features 5 image	/e/9/e9878f55eb6b5384141c5dddd3b14c0bf5eb8d06_ABR52D_287421004A20_detail05.jpg
Award 3 logo	no_selection
Award 1 logo	no_selection
Award 2 logo	no_selection
Certification CE logo	no_selection
Certification EAC logo	no_selection
FAQ 1 answer	Using this brushcutter petrol requires clothing that protects the legs and face from objects that could unexpectedly be thrown out during operation. It is always recommended to wear long trousers and a protective visor.
FAQ 1 question	What kind of protective gear should I use?
FAQ 2 question	What kind of maintenance should I carry out?
FAQ 2 answer	To ensure that the brush cutter is functioning correctly and to maximise its lifespan, we recommend regular (based on the frequency and intensity of use) cleaning of the air filter, sparking plug and cutting head (trimmer head and guard) – parts where a lot of dirt constantly builds up.<br />Remember that it is important to consult the user and maintenance manual for details of each of these tasks.
FAQ 3 question	Which type of grass and shrubs can you work on?
FAQ 3 answer	This petrol brush cutter is able to tackle coarser plant conditions, from dense bushes with tall grass to shrub areas, where you can also cut the more stubborn plants and shrubs using the supplied metal blade.
FAQ 4 question	How do you adjust the length of the line?
FAQ 4 answer	This model is fitted with a head using the Tap&Go system. This means that, while the machine is operating, you just have to press the control lever all the way to bring the head to maximum rotation and at the same time knock the head against the ground, which causes the line to feed out automatically. Its length can be adjusted simply, by cutting any excess to the length of the cutting blade located on the end of the guard.<br />For further information, see the instruction manual.
FAQ 5 question	The line no longer feeds out from the head. What might have happened?
FAQ 5 answer	The line failing to feed out may be associated with two main factors. The first, and the most likely, is that the line might be all used up and should therefore be replaced with a new reel. There is also the possibility that the line within the head has accidentally become caught in its own windings, and is preventing the end from freely feeding out through the holes. In this case, simply open the head and re-spool the line correctly inside.<br />These causes and solutions normally cover the majority of cases, but there may be a variety of others, associated with the methods of use, the surface treated and the weather conditions.<br />Note that consulting the user manual, in the section relating to the cutting head, may provide useful information for identifying the nature of the problem.
Power	1.55 kW
Power source	Petrol 2-stroke
Displacement	51.7 cm³
Engine rotation speed	9500 rpm
Maximum engine speed	9500 rpm
Idling speed (+/- 100)	3100 rpm
Starter	Easy start recoil
Primer	Yes
Choke	Manual with automatic return
Fuel tank capacity	1 l
Carburettor type	Butterfly valve
Ignition coil type	Digital
Air filter type	Paper
Maximum working area	0.000000
Nylon line diameter (millimeter)	2,8
Cutting width	45 cm
Nylon head type	Tap & Go dual line
Nylon line length	4 m
Blade type	3 T
Blade diameter	255 mm
Handle type	Bike
Vibe Control System (VCS)	Yes
Shaft type	Straight
Shaft tube diameter	28 mm
Inner shaft diameter	8 mm
Soft grip handle	Yes
Harness	Double
Included tools kit	Spark plug key, screwdriver
Guaranteed sound power level (LwA) - dB(A)	116
Vibration level right handle (m/s2)	4.85
Vibration level left handle (m/s2)	4.49
Measured sound pressure level at operator ear dB(A)	100.8
Measured sound power level dB(A)	115
Pack weight	14.5 kg
Product weight without cutting system	8.25 kg
Product length	1880 mm
Product width	684 mm
Product height	430 mm
Product weight	9.050000
What's in the box	Nylon head<br />Metal blade<br />Harness<br />Plastic bottle<br />Screwdriver<br />Socket spanner
SKU	287421004/A20

Write Your Own Review

ABR 52 D

Find a distributor

Key features

Product details and specs

Get rid of overgrown grass

This brushcutter is the perfect tool to face any kind opf overgrown grass and thick vegetation.

The combination of control and comfort

The bike-style handle gives you total control on the cutting zone and more comfort for long working sessions.

Get cutting!

Easy Start makes getting going fast and stress-free.

Easily advance the line

Advance the line by simply tapping the cutter-head on the ground!

Less stress on arms and back

The double harness enhances working comfort and avoids any kind of stress on arms and shoulders.

Technical specs

General info

EAN/UPC	8008984833449
SKU	287421004/A20

Cutting system

Nylon line diameter (millimeter)	2,8
Cutting width	45 cm
Nylon head type	Tap & Go dual line
Nylon line length	4 m
Blade type	3 T
Blade diameter	255 mm

Tools kit

Included tools kit	Spark plug key, screwdriver

Overall dimensions

Pack weight	14.5 kg
Product weight without cutting system	8.25 kg
Product length	1880 mm
Product width	684 mm
Product height	430 mm
Product weight	9.05 kg

Power

Power	1.55 kW
Power source	Petrol 2-stroke
Displacement	51.7 cm³
Engine rotation speed	9500 rpm
Maximum engine speed	9500 rpm
Idling speed (+/- 100)	3100 rpm
Starter	Easy start recoil
Primer	Yes
Choke	Manual with automatic return
Fuel tank capacity	1 l
Carburettor type	Butterfly valve
Ignition coil type	Digital
Air filter type	Paper
Maximum working area	0 ㎡

Equipment

Handle type	Bike
Vibe Control System (VCS)	Yes
Shaft type	Straight
Shaft tube diameter	28 mm
Inner shaft diameter	8 mm
Soft grip handle	Yes
Harness	Double

Vibration and noise data

Guaranteed sound power level (LwA) - dB(A)	116
Vibration level right handle (m/s2)	4.85
Vibration level left handle (m/s2)	4.49
Measured sound pressure level at operator ear dB(A)	100.8
Measured sound power level dB(A)	115

What's in the box

Nylon head
Metal blade
Harness
Plastic bottle
Screwdriver
Socket spanner

Support

Manuals Faqs

Trimmer lines guide Download

User manual Download
What kind of protective gear should I use?

Using this brushcutter petrol requires clothing that protects the legs and face from objects that could unexpectedly be thrown out during operation. It is always recommended to wear long trousers and a protective visor.
Which type of grass and shrubs can you work on?

This petrol brush cutter is able to tackle coarser plant conditions, from dense bushes with tall grass to shrub areas, where you can also cut the more stubborn plants and shrubs using the supplied metal blade.
The line no longer feeds out from the head. What might have happened?

The line failing to feed out may be associated with two main factors. The first, and the most likely, is that the line might be all used up and should therefore be replaced with a new reel. There is also the possibility that the line within the head has accidentally become caught in its own windings, and is preventing the end from freely feeding out through the holes. In this case, simply open the head and re-spool the line correctly inside.
These causes and solutions normally cover the majority of cases, but there may be a variety of others, associated with the methods of use, the surface treated and the weather conditions.
Note that consulting the user manual, in the section relating to the cutting head, may provide useful information for identifying the nature of the problem.

What kind of maintenance should I carry out?

To ensure that the brush cutter is functioning correctly and to maximise its lifespan, we recommend regular (based on the frequency and intensity of use) cleaning of the air filter, sparking plug and cutting head (trimmer head and guard) – parts where a lot of dirt constantly builds up.
Remember that it is important to consult the user and maintenance manual for details of each of these tasks.
How do you adjust the length of the line?

This model is fitted with a head using the Tap&Go system. This means that, while the machine is operating, you just have to press the control lever all the way to bring the head to maximum rotation and at the same time knock the head against the ground, which causes the line to feed out automatically. Its length can be adjusted simply, by cutting any excess to the length of the cutting blade located on the end of the guard.
For further information, see the instruction manual.
